  Recent Products
  • Wilo Yonos Para Pump Esbe Mixing Blending Valve

    T3 Control Group for Emmeti UFH Manifolds & Other Manifolds

    from £159.00
    The nickel plated T3 UFH pump control unit includes full temperature management, complete with a pre-wired Wilo Yonos Para RS25/6-RKA high efficiency circulating pump, EuP class A, adjustable thermostatic mixing valve from 35°C to 60°C, built-in temperature gauge measuring mixed water temperature, 1"M swivel joints for fast connection to 1" female underfloor heating manifold. Each pump control group has a built-in non-return valve in the flow elbow to allow system to be flushed and filled very easily when commissioning the underfloor heating system. T3 Thermostatic mixing valve - dial type with tamper proof cover. T3 Pump Controller is suitable for any underfloor heating manifold with connections on 210mm centres such as Emmeti,Ivar,Uponor,Komfort and many other manifold suppliers. This unit is compatible Emmeti U9700090 T3 Control Group (thermostatic mixing valve and pump). Optional Quarter turn red and blue ball valves are available for fitting to 1” M flow and return connections offers savings eliminating the need to drain the system down.

    “Manufacturer of the Year”

    Pump Industry Awards – Finalists.

    Wilo are proud to announce that we have been named finalists in the Pump Industry Awards 2016 “Manufacturer of the Year” category.

  • Komfort UFH TouchScreen Glacier White Programmable Thermostat

    Komfort UFH TouchScreen Glacier White Programmable Thermostat

    £34.99

    The Glacier White Komfort UFH TouchScreen programmable thermostat for water underfloor heating systems.

    5 year warrantyOffers -
    • Large LCD clear screen with blue backlight display and double temperature display mode showing the actual and the target temperature.
    • 24 hour time and day of the week display.
    • 6 period programmable time and temperature settings ~ offering both comfort and economy setting of you own personal choice.
    • 7 day programming available.
    • Room temperature is displayed on increments of 0.5°C.
    • Memory storage in event of power failure.
    • The Komfort Touch Thermostat room temperature is programmed for automatic operation.
    • With optional remote floor sensor.
    • The Komfort Touch programmable thermostat can be also lock to stop any unauthorised adjustment.
    • Also available in Sapphire Black
    The Touchscreen thermostat overall width 86mmx86mm, the programmable thermostat will project by only 14mm when fitted , with 25mm depth within the wall. (This touchscreen thermostat is not suitable for use with electric underfloor heating systems). The thermostat is IP 20 rated.

  • Giacomini 2 Wire 230 v Thermal Actuator R478 Normally Open

    Giacomini 2 Wire 230 v Underfloor Thermal Actuator R478 Normally Open

    £18.95
    Made in EuropeGiacomini Hep2o Thermal Actuator 230v 2 wire R478V The actuators of the R478 series are normally open (NA). They allow them hydraulic supply of the circuits when there is no voltage and they have a cable with two conductor for the connection to room thermostats or adjustment regulators. The R478M version has a stroke end micro-switch for driving circulators or zone valves. The R478V version has varistor for installation on places where the network voltage undergoes sudden changes that could damage the electronic components. The R478MV version has either varistor or stroke end micro-switch. In radiant panel heating and cooling systems, the normally open electrical actuators are to be preferred as they are not supplied for most of the time involving a sensible electric energy saving. Description In order to allow an optimal control of the room temperature, combining the energy saving with a high comfort, the use of electrical actuators on distribution manifolds, on radiator valves with thermostatic option, or on fancoil valves is advisable. The series of R478 electrical actuators is characterised by an absolute quiet operation, long lasting lifetime as it has no mechanism subjected to wear and a sufficiently slow closing to prevent from water hammer phenomenon. The operation mechanism is made of wax bulbs controlled by low consumption electrical PTC (Positive Temperature Coefficient). Technical data • Product in compliance with the Directives B.T. 73/23/CEE and 93/68/CEE and ENEC 03 Certificate • Product category: “Electrical actuators for assembly on radiators or radiant panel systems” • Condition in absence of voltage: - Normally Open “NO” (R478) • Linear motion • Valve working stroke 2,4 mm • Dust protection class 2 • Electrical discharge voltage 4 kV • Electrical enclosure to IP40 • Protection against direct contracts by means of double insulation (Class II) • Supply cable type H05 VV-F, useful length 1,5 m • Opening time at ambience temperature for R478/R478V/R478M/R478VM versions, 230 V - 24 V ≈ 6 minutes • Working room temperature: -5÷50 °C • Storage room temperature: -20÷65 °C • Casing material flame retardant PBT V0-UL94 • Vertical assembly above the valve, or horizontal • Rapid connection for Giacomini standard • Valve position mechanical indicator • Micro-switch NC with open valve (R478M - R478MV) Normally dispatched in 3-4 days
  • Underfloor Heating 4 Zone Master Control Wiring Centre / Unit

    Watts / Komfort 4 Zone Master 230v Control Wiring Centre / Unit

    £46.95

    Komfort 4 Zone Master Control Wiring Unit 230v

    with Visible Heating Zones, Boiler and Pump Lights compatible with Polypipe and Speedfit Master wiring centres
  • 24 v Mohlenhoff Underfloor Heating Actuator

    Mohlenhoff 24 volts Thermoelectric Actuator 2 Wire/Core

    £22.15
    Mohlenhoff Thermoelectric UFH Actuator Head 24 volt 2 Wire (2 core). Adaptor ring for connection on on to the underfloor heating manifolds with M30 thread (which is the most popular underfloor heating manifold thread size). This Underfloor Heating Actuator Head is made in Germany by Mohlenhoff

    This actuator will replace a 2 wire Gabotherm, Polypipe Polyplumb,  Wavin, Nuheat, Speedfit, Robins, Thermoboard actuators.

  • Tray-100

    Underfloor Heating Plastic Castellated Floor Panels (Select Qty)

    £4.99

    The Molded Plastic Castellated Floor Panels / Egg Box Trays  100% Recycled Plastic

    24550542_m     Proud to be Made here in the  UK  The Floor Panels will give optimum performance in your Underfloor Heating System, the floor trays allow for a fast installation together with accurate fixing of underfloor heating pipes. The knob system floor tray holds the pipe securely in place by the castellated knobs, the underfloor  panel also acts as a pipe fixing template ensuring accurate spacing of pipes allowing a even heat distribution. Our unique floor panels are lightweight and can be easily cut to size to fit any room shape. The underfloor pipe trays are provided in black, they are neatly overlapped to create a fully interlocking continuous grid floor panel ready for the pipes which can be fixed at 100, 200 & 300 mm pipe centres. This floor panel will interlock with the red floor panels with dimensions of  1.20 x 1.0 m with 100 mm pipe centres. The underfloor pipes are securely held in position before and during the laying of the floor screed. Features and Benefits
    • Made from Recycled High Impact Polystyrene
    • Easy to install
    • Minimum amount of waste
    • Eliminates pipe contact with insulation
    • Total size 1220 mm x 820 mm x 30 mm
    • Pipe Centres can be at 100 mm, 200 mm & 300 mm
    • Each Panel will cover approx 1 square metre
    Colour Black
    • Ideal for use with heat pumps
    • Pipe Diameter 15 mm - 16 mm

    Prices from £4.15

    The more you buy the cheaper the price becomes, for bulk quantities above 1000 trays, please call us and we will quote you accordingly.

  • Polypipe Underfloor Heating Actuator

    Polyplumb Replacement 2 Wire Underfloor Actuator 230v for UFCH Polyipe PB00401 and J G Speedfit

    £14.85
    2 Wire - 230volts Underfloor Heating Manifold Actuator Compatible Replacement for Polypipe UFCH Polyplumb PB00401 This actuator was also used with Speedfit and will be a compatible replacement.
  • Underfloor Single Circuit Pump Control, Programmable Thermostat & Valve

    Underfloor Single Circuit Pump Control , Programmable Thermostat & Valve

    from £369.91

    Room Temperature Single Circuit Pump Control Pack

    Made in EuropeThe Komfort Temperature Control Pack is all you the electrical components that you will require to operate the single underfloor heating circuit to fire the boiler and main heating pump. The Komfort Underfloor Temperature Control Pack will satisfy 3 kw of heating surface area. The Pack comprises of - 1 x A Rated Wilo Single Circuit Pump Unit 1 x 2 way Straight Valve with 15mm Copper pipe connections 1 x 4 wire Actuator 1 x Thermostat of your choice. Connects for your underfloor heating pipework will need to be purchased separately from https://underfloorparts.co.uk/product-category/pipe-fitting-adaptors/ Pipe and wiring details can be supplied.

    "Manufacturer of the Year"

    Pump Industry Awards - Finalists.

     Wilo are proud to announce that we have been named finalists in the Pump Industry Awards 2016 "Manufacturer of the Year" category.


  • 20m² x 18mm Gypsum Overlay Underfloor Heating System & Pump Control Unit 1

    20m² x 18mm Gypsum Overlay Underfloor Heating System & Pump Control Unit

    £791.00

    20m² Komfort Low Profile Underfloor Heating System

    Made in EuropeKomfort 18 mm Low Profile Underfloor Heating System The Komfort underfloor heating low profile floor system is the perfect solution for both renovation and new build projects. This Komfort Overlay system can be installed over the existing floor with a low build height of only 18 mm. When using these Komfort underfloor heating panels, the costly need to remove any existing floors is eliminated as the UFH Overlay panels can very simply fit on top of the existing floor. The Komfort UFH Overlay panel offers the perfect answer for a wood or tile floor finish. The Overlay panel design contributes to an easier installation when using these floor finishes and furthermore, when using with a ceramic floor finish, an outstanding 99 watts /m² can be achieved (this will depend on floor finishes etc..) The UFH panels can be used on ground and upper floors. The Komfort UFH 18 mm Overlay panels are DFE (gypsum fibre) made from non flammable Fermacell Gypsum Fibreboard which offers top quality dry flooring elements (DFE), and will integrate with any existing heating system. Approvals - European Technical Approval ETA-03/0050                       eco-INSTITUT Tested Product:                       Certificate no ID 0907 – 13701 – 001                       Certificate no ID 0907 – 13701 – 002                       Certificate no ID 0907 – 13701 – 003 Copies of these certificate are available upon request. While some Overlay panels offer only one option of pipework layout, another benefit of the Komfort Overlay DFE Panel is the practicality of installation as it offers the user a choice of pipework design. In addition to this, a quicker installation can be achieved due to the superior design of the Komfort Overlay panels as the need for return panels is eliminated. This allows the 1200 mm x 600 mm universal panels and Komfort 12 mm 5 Layer PE-RT oxygen barrier pipe to be installed with greater ease, making it one of the most flexible Overlay fixing systems in the market. 10 year complete system guarantee (excluding any electrical components). This pack is heavy and requires unloading facilities, PALLET DELIVERY to England, Wales, Scottish Lowlands and mainland. If there is no unloading facility on site please contact the number below to arrange for a tail lift facility. Any Deliveries to Islands and Scottish Highlands price on application.

    If you are uncertain of your requirements or your require a specific area, please telephone 01600 710909 for assistance.

  • Underfloor Heating Fit From Below FFB Aluminium Spreader Plates

    Underfloor Heating FFB 250mm Fit From Below Double Spreader Plates

    £4.27
    24550542_mThe UK Made Komfort Underfloor Heating Double Spreader Plate,  fit from below (FFB) aluminium spreader plates, the FFB double spreader plate system is designed to be installed from underneath the already fitted floor boards are already installed and underfloor heating is required. The fit from below ( FFB) double heat spreader plate is designed for joist spacing of 400mm centres, where joist centres are wider - please contact us and we will quote you for your specific requirements. Pipe centres are 250 mm allowing maximum spreader plate contact with the underside of the floorboard. UFH FFB Double Spreader Plate dimensions 1000 x 266 mm Our FFB aluminium fit from below ufh double heat spreader plate also works well with TJI, Silent Floors,Eco Joists,BCI,Trus Joist  Pozi-Joists.
  • 10m2 Fermacell 18mm Overlay Underfloor Heating System & Pump Controls 1

    10m2 Fermacell 18mm Overlay Underfloor Heating System & Pump Controls

    £492.00

    10m2 Komfort Low Profile Underfloor Heating System

    Made in EuropeKomfort 18mm Low Profile Underfloor Heating System The Komfort underfloor heating low profile floor system is the perfect solution for both renovation and new build projects. This Komfort Overlay system can be installed over the existing floor with a low build height of only 18mm. When using these Komfort underfloor heating panels, the costly need to remove any existing floors is eliminated as the UFH Overlay panels can very simply fit on top of the existing floor. The Komfort UFH Overlay panel offers the perfect answer for a wood or tile floor finish. The Overlay panel design contributes to an easier installation when using these floor finishes and furthermore, when using with a ceramic floor finish, an outstanding 99 watts /m² can be achieved (this will depend on floor finishes etc..) The UFH panels can be used on ground and upper floors. The Komfort UFH Overlay panels are DFE (gypsum fibre) made from non flammable Fermacell Gypsum Fibreboard which offers top quality dry flooring elements (DFE), and will integrate with any existing heating system. Approvals - European Technical Approval ETA-03/0050                       eco-INSTITUT Tested Product:                       Certificate no ID 0907 – 13701 – 001                       Certificate no ID 0907 – 13701 – 002                       Certificate no ID 0907 – 13701 – 003 Copies of these certificate are available upon request. While some Overlay panels offer only one option of pipework layout, another benefit of the Komfort Overlay DFE Panel is the practicality of installation as it offers the user a choice of pipework design. In addition to this, a quicker installation can be achieved due to the superior design of the Komfort Overlay panels as the need for return panels is eliminated. This allows the 1200 mm x 600 mm universal panels and Komfort 12 mm 5 Layer PE-RT oxygen barrier pipe to be installed with greater ease, making it one of the most flexible Overlay fixing systems in the market. 10 year complete system guarantee (excluding any electrical components). This pack is heavy and requires unloading facilities, PALLET DELIVERY to England, Wales, Scottish Lowlands and mainland. If there is no unloading facility on site please contact the number below to arrange for a tail lift facility. Any Deliveries to Islands and Scottish Highlands price on application

    If you are uncertain of your requirements or your require a specific area, please telephone 01600 710909 for assistance.

  • Watts 230v 2 wire Underfloor Heating Electrothermic Actuator

    Watts 230v 2 wire Underfloor Heating Electrothermic Actuator 26LC

    £12.95
    Made in Europe Watts 230 volts 2 Wire Underfloor Heating Electro Thermic Actuator.
    • 1.8 watts Low Power Consumption
    • I.P 64 Rated which could be fitted within a Bathroom
    • Actuator can be installed 360°
    • Simple Plug in Cable with Safety Catch
    • Opening Time - Initial 75 seconds ~Final 3 minutes
    • Actuator Stroke - Max 3.5mm
    • Valve Stroke - 2.5 mm
    • Operating Temperature - 0° - 50° C
    • Maximum Fluid Temperature - 110° C
    • Flame Retardant Plastic Cover and Components
    • Cable Length 1 mtr x 0.5mm²
    • Ring Nut M30 x 1.5 Thread
    .
  Welcome to Underfloor Parts

A warm welcome to Underfloor Parts, the online website where you can find all of your warm water underfloor heating requirements from a full underfloor heating system to a component spare part, all in one place.

Please browse through our website for any of your underfloor heating needs, from complete underfloor heating systems for wooden to solid floor applications to underfloor heating spare parts.  We sell underfloor heating packs / kits to individual underfloor heating part or a single component part for your underfloor heating system. Many of our products are universal and fit any of the other underfloor heating manufacturers systems which will allow you to save money on your underfloor heating replacement spare part for your system at a lower prices.  We are pleased to supply many well known high quality branded underfloor heating products at very competitive prices. We believe in supply quality underfloor heating parts for many years of reliable use.

Need advice? Call our friendly sales team on 01600 710909 who will be happy to receive your call on your underfloor heating system or underfloor heating spares queries.
